Hikvision DS-2CD2743G2-IZS 4 MP AcuSense Motorized Varifocal Dome Network Camera

Hikvision DS-2CD2743G2-IZS 4 MP AcuSense Motorized Varifocal Dome Network Camera

Camera Specifications

Image Sensor

• Type: 1/3″ Progressive Scan CMOS
• Max. Resolution: 2688 × 1520

Min. Illumination

• Color: 0.005 Lux @ (F1.6, AGC ON)
• IR: 0 Lux with IR on

Shutter Time

• Range: 1/3 s to 1/100,000 s

Day & Night

• ICR Cut: Yes

Angle Adjustment

• Pan: 0° to 355°
• Tilt: 0° to 75°
• Rotate: 0° to 355°

Lens

• Type: Varifocal, motor-driven lens
• Focal Length: 2.8 to 12 mm
• FOV:
  • Horizontal: 95.8° to 29.2°
  • Vertical: 50.6° to 16.4°
  • Diagonal: 114.6° to 33.4°
• Lens Mount: Ø14
• Aperture: F1.6

DORI (Detection, Observation, Recognition, Identification)

• 2.8 to 12 mm:
  • Detection: 64 m to 200 m
  • Observation: 25.4 m to 79.4 m
  • Recognition: 12.8 m to 40 m
  • Identification: 6.4 m to 20 m

Illuminator

• Type: IR
• Range: Up to 40 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm

Video

• Main Stream:
  • 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream:
  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
• Third Stream:
  • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• Compression:
  • Main stream: H.265/H.264/H.264+/H.265+
  • Sub-stream: H.265/H.264/MJPEG
  • Third stream: H.265/H.264
• Bit Rate: 32 Kbps to 8 Mbps

Audio

• Compression: G.711ulaw, G.711alaw, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC
• Bit Rate:
  • G.711ulaw/G.711alaw: 64 Kbps
  • G.722.1: 16 Kbps
  • AAC-LC: 16-64 Kbps
  • MP3: 8-320 Kbps
• Sampling Rate: 8 kHz, 16 kHz, 32 kHz, 44.1 kHz, 48 kHz
• Environment Noise Filtering: Yes

Network

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket
• Simultaneous Live View: Up to 6 channels
• API: ONVIF (Profile S, Profile G), ISAPI, SDK
• Security: Password protection, HTTPS encryption, IP address filter, Security Audit Log

Storage

• Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
• On-Board Storage: Built-in microSD, up to 512 GB

Alarm

• Inputs/Outputs:
  • 1 input, 1 output (max. 12 VDC, 30 mA)
• Events: Motion detection, video tampering, line crossing, intrusion detection, face detection
• Linkage: FTP upload, memory card, NAS, email, trigger record/capture

General

• Power:
  • 12 VDC ± 25%, 0.88 A, max. 10.5 W
  • PoE: 802.3af, Class 3, 36 V to 57 V, max. 12.5 W
• Material: Metal (Upper cover & base), Plastic (Bubble)
• Dimension: Ø153.3 × 111.6 mm (Ø6.1″ × 4.4″)
• Weight: Approx. 880 g (1.9 lb.)
• Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% max.
• Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% max.

Approvals

• EMC: FCC, CE-EMC, RCM, IC, KC
• Safety: UL, CB, CE-LVD, BIS
• Environment: CE-RoHS, WEEE, Reach

Protection

• IP Rating: IP67
• IK Rating: IK10
