EZVIZ DP2C 1080p Peephole Camera with 4.3" Color Screen Display, Built-in Chime, and Rechargeable Battery

EZVIZ DP2C 1080p Peephole Camera with 4.3" Color Screen Display, Built-in Chime, and Rechargeable Battery

EZVIZ DP2C 1080p Video Door Viewer

Model: CS-DP2C

Installation Parameters:

• Supported Hole Diameter: 16.5 to 50 mm (0.65 to 1.97 inch)
• Supported Door Diameter: 35 to 105 mm (1.38 to 4.13 inch)

Camera Parameters:

• Sensor: 1/3" Progressive Scan CMOS
• Lens: 2.0 mm @ F2.2, Visual Angle (Diagonal): 155°
• Day/Night Switch: ICR infrared filter
• IR Distance: Max. 5m
• Max. Resolution: 1080p / 2MP
• Video Frame Rate: 15fps

PIR Detection:

• Angle: 110°
• Distance: Max. 6m (20 ft)
• Sensitivity: Adjustable

Interface:

• Storage Interface: MicroSD card slot (Max. 512 GB)
• Audio Input: Built-in high sensitivity microphone
• Audio Output: Built-in high-power speaker
• Buttons: Doorbell button, Power button, Screen wake-up button

Network:

• Face Detection: Does not support
• Intelligence Alarm: PIR motion detection
• Protocol: EZVIZ Cloud Proprietary Protocol
• Video Intercom: Local and remote video intercom
• General Function: Cloud video encryption and image encryption

Wireless:

• Wi-Fi Standard: IEEE802.11b/g/n
• Frequency Range: 2.4 GHz ~ 2.4835 GHz
• Channel Bandwidth: Supports 20 MHz
• Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
• Transmission Rate:
  • 11b: 11 Mbps
  • 11g: 54 Mbps
  • 11n: 150 Mbps

General:

• Screen: 4.3-inch color screen
• Color Options: Silver/Golden
• Operating Conditions: -10°C to 45°C (14°F to 113°F), Humidity 95% or less (non-condensing)
• Power Supply: DC 5V (±10%)
• Power Consumption: Max. 2.2W
• Dimensions:
  • Screen and Base: 115.5 x 85.5 x 24.5 mm (4.55 x 3.37 x 0.96 inch)
  • Peephole Doorbell: 71 x 71 x 48.3 mm (2.80 x 2.80 x 1.90 inch)
• Weight: 302 g (10.65 oz)

In the Box:

• DP2C Peephole Doorbell
• Panel
• Mounting Base
• Power Cable
• Screws × 6
• Quick Start Guide

Certifications:

• UL / FCC / CE / WEEE / REACH / RoHS
